The Palladium amplifier range HAS proven itself for many years. They give real power and save to your speakers. Almost 15 years of production time and about 60,000 Palladiums oversold the palladium is a real standard in the industry. You can choose between the silver vintage look or the black look. If you need reliability, real and safe power in an affordable price range the Palladium amplifier range is what you need.
Specifications
Output Power, 1000 Hz, THD + N at 1%Both Channels Driven:
Stereo mode: 8 Ohm: 2x 240 Watt RMS
4 Ohm: 2 x 360 Watts RMS
2 Ohm: Not Allowed
Bridge mode: 8 Ohm: 720 Watts RMS
4 Ohm: Not Allowed
Frequency Response: 20 - 45.000 Hz -1 dB
THD + N <0.05%
Intermodul. Distortion: <0.01%
Damping Factor at 8 Ohm:> 250
Slew Rate:> 40 V / mS
Input CMRR:> 60 dB
Cross Talk 20 - 20.000 Hz:> 60 dB
Signal to Noise Ratio:> 105 dB A-weighted
Input Sensitivity: 1 V ~ +2.2 dBu
Max. Input Voltage: +22 dBu
Input Impedance: 20 Ohm Balanced
10 ohm Unbalanced
Protection: Clip Limiter (Fixed)
Short Circuit
input Overload
output Overload
DC Voltage
high Temperature
Output Modes (Select.): Stereo / Parallel / Bridge
Cooling: Dual Speed ​​Fan
Airflow: Front to Back
Input / Link Connector: XLR / Jack
Output Connector: 2x Speakon,
2 Pair Bindings Posts
Ground Lift Switch: Yes
Dimensions (LxWxH): 483 x 430 x 89 mm
Net Weight: 13.44 kg
Power Supply: 200-240 VAC, 50 Hz
Main Fuse: 8AT, 5 x 20 mm
Power consump. (2 x 4 Ohm): 1100 Watt
