Nominal Input Level -20 dBu

Input Impedance 1 M ohm

Nominal Output Level -20 dBu

Output Impedance 1 k ohm

Recommended Load Impedance 10 k ohms or greater

Bypass Buffered bypass

Controls

DRIVE knob
TONE knob
LEVEL knob
Pedal switch

Indicator CHECK indicator (Used for indication of check battery)

Connectors

INPUT jack: 1/4-inch phone type
OUTPUT jack: 1/4-inch phone type
DC IN jack

Power Supply

Carbon-zinc battery (9 V, 6F22) or Alkaline battery (9 V, 6LR61)
AC adaptor (PSA series: sold separately)

Current Draw 15 mA

Expected battery life under continuous use

Carbon: Approx. 34.5 hours
Alkaline: Approx. 56 hours
*These figures will vary depending on the actual conditions of use.

Accessories

Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
Carbon-zinc battery (9 V, 6F22)

Options (sold separately)

AC adaptor: PSA series

SIZE AND WEIGHT

Width

73 mm
2-7/8 inches

Depth

129 mm
5-1/8 inches

Height

59 mm
2-3/8 inches

Weight (including battery)

370 g
14 oz

* 0 dBu = 0.775 Vrms

*The specifications are subject to change without notice.
